Dedicated Expertise and Infrastructure
When you need the unquestioned results that only come from the most highly qualified testing facilities with a highly skilled and knowledgeable staff, you can be confident that Boeing will deliver the electromagnetics testing results you want.
Large or small, aerospace, automotive, industrial or military, Boeing’s testing facilities can support almost any electromagnetic testing that you have. The demands of electromagnetic effects confront Boeing daily in its commercial and military markets. Capitalize on that dedicated expertise and infrastructure.
Bring your electromagnetics testing requirements to Boeing. Be confident that Boeing works for you.
Antenna and Radar Cross-Section Testing
Boeing antenna and radar cross-section (RCS) testing ranges consist of indoor and outdoor facilities suitable for measuring nearly any test article at a variety of locations across the United States. Many of these test ranges can collect antenna pattern and RCS data on the same test articles. Boeing test engineers are highly skilled, and the test facilities are highly configurable, allowing unique and hard-to-find test capabilities to be provided.
Small Compact Ranges for RCS and Antenna Patterns
- Test articles up to 10 ft. in length
- 500 MHz to 50 GHz
Very Large Compact Range for RCS and Antenna Patterns
- Test articles up to 50 ft. in length
- 120 MHz to 40 GHz
Near-Field RCS Range
- Test articles up to 70 ft. in length
- 2 to 18 GHz
Small and Large Near-Field Antenna Scanners
- Test articles up to 50 ft. in length
- 4 to 100 GHz
Outdoor Antenna Ranges
- Test articles up to 70 ft. in length
- 30 MHz to 50 GHz
Electromagnetic Interference and Compatibility
Boeing offers a wide range of electromagnetic interference and compatibility (EMI/EMC) testing of electronic devices, components, subsystems, and systems in dedicated, certified shield rooms and anechoic chambers. Highly skilled test teams also perform aircraft certification testing (such as safety of flight) on operational production and experimental aircraft and can be deployed around the world.
EMI/EMC Chambers
- Certified shield rooms of various sizes
- Anechoic and mode-stirred chambers
- Operations with MIL-461, MIL-462, and DO-160 standards
- National Voluntary Laboratory Accreditation Program–certified laboratory
Aircraft System Testing
- Safety-of-flight certification
- High-intensity radiated field
- Production and experimental aircraft
- Worldwide deployment
Direct and Indirect Lightning Effects
Boeing offers testing of direct and indirect lightning effects using high-voltage and high-current waveforms. The highly skilled electromagnetic effects test engineers can often develop innovative test methods for prototype or difficult-to-handle test parts.
Direct Effects Testing
- Composite structures, surfaces, and installations
- Composite bonding and grounding
- Lightning protection systems
- Fastened and bonded joint testing
- High-voltage arc attachment (2 megavolt peak)
- Airplane system safety verification
- Precipitation static testing
- RTCA DO160, Section 23
- Consistent with MIL-STD 461
- Wide variety of waveforms
Indirect Effects Testing
- Certified shield rooms
Radio Frequency and Infrared Material Properties
Boeing materials measurement laboratories offer destructive and nondestructive RF and IR testing of material electrical properties. In addition to typical material testing (such as permittivity, permeability, reflectance, and transmittance), the highly skilled staff routinely develops innovative testing methods and fixtures for hard-to-test materials such as liquids and adhesives.
RF Material Testing
- Waveguide bands: 410 megahertz to 18 gigahertz
- Coaxial: 45 megahertz to 18 gigahertz
- Free space: 2 to 110 gigahertz
- Pressed waveguide: 2.6 to 18 gigahertz
- Resonant cavities: 1.1 and 8 to 26 gigahertz
- Bistatic (arch) fixtures
- X/Y scanner for large samples
- High temperature
- In-service field testing
- Custom test equipment development and design
IR Material Testing
- Reflectance
- Diffuse, specular, total from ambient to Elevated Temperatures
- Ultraviolet (UV), visible (Vis), near IR (NIR), IR
- Grazing angle at laser lines
- Transmission
- Specular, total hemispheric
- UV, VIS, NIR, IR
- Scatter bidirectional reflection distribution function (BRDF)
- 360-degree, reflection, transmission
- Selected lines, VIS, NIR, IR
- Haze
- Gloss
